SPECIFICATION
frame
Advanced SL-grade composite front and rear triangles, 120mm FlexPoint Pro suspension, flip chip, 12x148mm thru-axle
fork
RockShox Sid Ultimate 3P, 120mm, Charger Race Day 2 damper, Boost 15x110, 44mm offset, remote lockout
shock
RockShox SidLuxe Ultimate, RL damper, Solo Air, 210/50, TwistLoc Ultimate
handlebar
Giant Integrated XC, composite, 780mm, 9-degree upsweep
grips
SRAM TwistLoc Ultimate
stem
Giant Integrated XC Carbon, S:60mm, M:70mm, L:70mm, XL:80mm
seatpost
Giant Contact Switch SL dropper, remote S: 110mm travel / 30.9 x 395mm M: 140mm travel / 30.9 x 395mm L: 140mm travel / 30.9 x 395mm XL:140mm travel / 30.9 x 395mm
saddle
Giant Grit SLR
pedals
N/A
shifters
SRAM AXS Pod, 1x12
front derailleur
N/A
rear derailleur
SRAM XX SL Eagle Transmission
brakes
SRAM Motive ULT, hydraulic, SRAM HS2 6-bolt rotors [F]180mm, [R]160mm
brake levers
SRAM Motive ULT
cassette
SRAM XS 1297 Eagle Transmission, 10x52
chain
SRAM XX Eagle Transmission
crankset
SRAM XX SL Eagle Transmission with Quark power meter, 34t, 55mm chainline S:170mm, M:170mm, L:175mm, XL:175mm
bottom bracket
SRAM DUB, press fit
rims
Giant XCR WheelSystem
hubs
[F] Giant MTB alloy, 6-bolt [R] Giant MTB alloy, 6-bolt
spokes
Carbon
tires
Maxxis Aspen 29x2.4, foldable, 120tpi, MaxxSpeed, EXO, tubeless
extras
Tubeless prepared, 2.4inch max tire size, 34t max chainring size, MRP 1x SL TR2 chain guide
weight
The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.
