GIANT STANCE E+ 1 PRO

SPECIFICATIONS

motor
SyncDrive Pro, 85Nm, powered by Yamaha

controller
RideControl Dash

display
RideControl Dash, full color lcd screen

battery
EnergyPak Smart 800, EnergyPak Plus 250Wh range extender compatible

sizes
S, M, L, XL

colors
Cordovan

frame
ALUXX SL-grade aluminum, 125mm travel FlexPoint suspension system, 148x12 rear axle, Universal Derrailleur hanger, 184x44 shock, 1.5~1.8in headset

fork
RockShox 35 Silver, 140mm, 1.8in tapered steerer, 110x15 Maxle Stealth

shock
SR Suntour Raidon R, 190x45mm, custom tuned

handlebar
Giant Connect TR Riser 31.8x780mm

grips
Giant Tactal single lock-on

stem
Giant Contact

seatpost
Giant Contact Switch, dropper, 30,9mm (S:125/M:150/ L&XL:170)

saddle
Giant Sport

pedals
Flat pedal

shifters
Shimano Deore

rear derailleur
Shimano Deore 12-speed

brakes
Tektro HD-M750 Orion, 4-piston, hydraulic disc, 203mm

brake levers
Tektro HD-M750

cassette
Shimano CS-M6100-12, 10-51T, 12-speed

chain
KMC e.12 Turbo, EcoProteq, e-bike optimized

crankset
FSA Comet E-Bike crank arm setFSA MegaTooth Direct-mount 1X steel 36T

bottom bracket
n/a

rims
Giant AM 29in, Tubeless ready, 30mm inner width

hubs
Shimano MT410 Boost, Center-Lock, [F] 110x15 [R] 148x12mm Micro-Spline Drive Body Thru-axle

spokes
Sapim E-Lite [R] Race [F], e-bike optimized

tires
Maxxis Minion DHF 29X2.50in Foldable, TLR, EXO, 60TPI [F]Maxxis Dissector 29X2.40in Foldable, WT, TLR, EXO, 60TPI [R]

extras

Tubeless kit (liquid, valves, levers, manual, tool)

lighting
-

lock
Torx 25 Battery Lock with built-in Torque limiter

carrier
-

weight
The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.
