SPECIFICATIONS
Frame
ALUXX-Grade aluminium, disc
Fork
SXC32-2 RL, air spring, Boost 15x110, S: 100mm travel, M: 100mm travel, L: 100mm travel, XL: 100mm travel
Shock
N/A
Handlebar
Giant Connect Trail, 31.8mm
Grips
Giant Sole-O
Stem
Giant Sport, 7-degree S: 50mm M: 60mm L: 70mm XL: 80mm
Seatpost
Giant Contact Switch Core dropper, remote S: 100mm travel / 30.9 x 350mm M: 125mm travel / 30.9 x 400mm L: 125mm travel / 30.9 x 400mm XL: 125mm travel / 30.9 x 400mm
Saddle
Giant ErgoContact Trail
Pedals
MTB caged
Shifters
Shimano Deore M6100, 1x12
Front Derailleur
N/A
Rear Derailleur
Shimano Deore M6100, Shadow+
Brakes
Shimano BR-MT200, hydraulic, Shimano RT-10 rotors [F]180mm, [R]160mm
Brake Levers
Shimano BL-MT201
Cassette
Shimano Deore M6100, 10x51
Chain
KMC X12
Crankset
ProWheel MPX, 30t S: 170mm M: 170mm L: 170mm XL: 175mm
Bottom Bracket
Cartridge
Rims
Giant GX03V 29, alloy, double wall
Hubs
[F] Shimano HB-TC500-15-B 110x15, Sealed [R] Shimano FH-TC500-MS 142x12, Sealed, HG
Spokes
Stainless, 14g
Tires
Maxxis Rekon Race 29x2.4", wire bead
Extras
2.4" max tyre size, 32t max chainring size
Weight
The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.
