GIANT TRANCE X ADVANCED E+ 1

SPECIFICATIONS

motor
SyncDrive Pro, 85Nm, powered by Yamaha

controller
RideControl GO integrated in TT, RideControl Ergo 3

display
ANT+ cycle computer compatible

battery
EnergyPak Smart 800, EnergyPak Plus range extender compatible

sizes
S, M, L, XL

frame
Advanced-grade composite frame, Advanced-grade rear triangle, Advanced forged composite upper rocker, 140mm Maestro suspension system

fork
Fox 36 Live Valve, 150mm travel, 44mm offset, Grip2 damper, Boost 110x15QR, electronic adaptive suspension, e-bike integrated, e-bike integrated

shock
Fox Float X Live Valve, 185x52.5mm Trunnion mount, electronic suspension, e-bike integrated

handlebar
Giant Contact SL 35, 35x780mm

grips
Giant Tactal Pro-E, single lock-on

stem
Giant Contact SL 35

seatpost
Tranz-X Rad+ travel adjust dropper, dropper, 30,9mm (S:100~140mm, M:140~170mm, L/XL:170~200mm)

saddle
Giant Romero, Neutral

pedals
Flat pedals

shifters
Shimano Deore XT

frontDerailleur
MRP HD2 co-moulded chain guide

rearDerailleur
Shimano Deore XT, 12-speed, Shadow+

brakes
Shimano Deore XT, BR-M8120, 4-piston, hydraulic disc, 220mm

brakeLevers
Shimano Deore XT, I-spec EV

cassette
Shimano CS-M7100, 10-51T, 12-speed

chain
KMC e.12 Turbo, EcoProteq, e-bike optimized

crankset
Praxis Wavetm 36T Cold Forged 4130 premium steel Praxis e-Cadet+ custom forged crankarm set (S:160mm, M/L: 165mm, XL:170mm)

bottomBracket
n/a

rims
e-TRX Hookless Clincher, 29in, 30mm inner width

hubs
e-TRX 6 Bolt, Shimano Micro-spline, 110 x 15 [F], 148 x 12 [R] Thru Axle

tires
Maxxis Minion DHF 29x2.6in foldable, Tubeless, EXO+, 3C MaxxTerra [F]Maxxis Dissector 29x2.6in Foldable, Tubeless, EXO+, 3C MaxxTerra [R]

extras
Tubeless kit (liquid, valves, levers, manual, tool)Inner tube supplied

lighting
Optional:- Giant Recon series e-bike lights available and direct connectable

lock
Torx 25 Battery Lock with built-in Torque limiter

weight
The most accurate way to determine any bike’s weight is to have your local dealer weigh it for you. Many brands strive to list the lowest possible weight, but in reality weight can vary based on size, finish, hardware and accessories. All our bikes are designed for best-in-class weight and ride quality.
